- Shaft inner diameter : Ø6mm
- Max. response frequency : 300kHz
- Max. allowable revolution : 5000rpm
- Starting torque : Max. 50gf.cm(max. 0.0049N.m)
- Resolution : 500P/R
- Control output : Totem pole
- Power supply : 12-24VDC
±5%(ripple P-P: max. 5%) - Connection type : Radial cable type
- Protection structure : IP50
| Shaft inner diameter | Ø6mm |
|---|---|
| Max. response frequency | 300kHz |
| Max. allowable revolution | 5000rpm |
| Starting torque | Max. 50gf.cm(max. 0.0049N.m) |
| Resolution | 500P/R |
| Output phase | A, B, Z |
| Control output | Totem pole |
| Power supply | 12-24VDC  ±5%(ripple P-P: max. 5%) |
| Connection type | Radial cable type |
| Protection structure | IP50 |
| Environment_Ambient temperature | -10 to 70℃, storage: -25 to 85℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 90% RH |
| Accessories | Bracket |
| Weight | Approx. 120g |
